- Department of Vascular Neurology, University Medical Center Ljubljana, Ljubljana, Slovenia
- Department of Neurosurgery, University Medical Center Ljubljana, Ljubljana, Slovenia
- Department of Neurosurgery, University of Dubrovnik, Dubrovnik, Croatia
Correspondence Address:
Senta Frol, Department of Vascular Neurology, University Medical Center Ljubljana, Ljubljana, Slovenia.
DOI:10.25259/SNI_245_2025
Copyright: © 2025 Surgical Neurology International This is an open-access article distributed under the terms of the Creative Commons Attribution-Non Commercial-Share Alike 4.0 License, which allows others to remix, transform, and build upon the work non-commercially, as long as the author is credited and the new creations are licensed under the identical terms.How to cite this article: Senta Frol1, Matija Zupan1, Janja Pretnar Oblak1, Tomaž Velnar2, Bruno Splavski3. Iatrogenic cerebral amyloid angiopathy: Two cases linked to childhood cadaveric dural transplantation for different intracranial pathologies, diagnosed using the simplified Edinburgh computed tomography criteria. 02-May-2025;16:165
How to cite this URL: Senta Frol1, Matija Zupan1, Janja Pretnar Oblak1, Tomaž Velnar2, Bruno Splavski3. Iatrogenic cerebral amyloid angiopathy: Two cases linked to childhood cadaveric dural transplantation for different intracranial pathologies, diagnosed using the simplified Edinburgh computed tomography criteria. 02-May-2025;16:165. Available from: https://surgicalneurologyint.com/?post_type=surgicalint_articles&p=13531
Abstract
BackgroundCerebral amyloid angiopathy (CAA) is an age-related condition marked by amyloid-β (Aβ) accumulation in the small cerebral vessels. Iatrogenic cerebral amyloid angiopathy (iCAA) is a distinct form of CAA in younger patients with a history of cranial surgeries involving cadaveric dural transplants. Both iCAA and CAA are linked to recurrent lobar intracerebral hemorrhage (ICH). This article highlights iCAA as a distinct variant, discussing the possibility of using simplified Edinburgh computed tomography (CT) criteria as a possible diagnostic tool for CAA and carefully considering plausible childhood surgery, with the risk of Aβ transmission through dural grafts in all, especially middle-aged patients.
Case DescriptionWe present two cases of iCAA in a 46-year-old female and a 52-year-old male who suffered recurrent spontaneous lobar ICHs. The CAA was diagnosed using the simplified Edinburgh CT criteria, leading to further investigations into the underlying pathology. Based on their age, iCAA was suspected, and only after a meticulous search of the hospital documentation it was discovered that they both underwent cranial surgeries in childhood involving cadaveric dural grafts. The diagnosis of iCAA was established using the proposed diagnostic criteria by Banerjee et al. and later confirmed by pathological examination.
ConclusionOur paper emphasizes the simplified Edinburgh criteria as a potential yet preliminary diagnostic tool for iCAA, while also highlighting the long-term risks of iatrogenic amyloid transmission related to dural grafting following various neurosurgical procedures.
Keywords: Amyloid-ß proteins, Cadaveric, Cerebral amyloid angiopathy, Dural allotransplants, Edinburgh criteria, Iatrogenic, Intracerebral hemorrhage, Lobar, Prion-like transmission, Recurrent, Simplified, Spontaneous
INTRODUCTION
Cerebral amyloid angiopathy (CAA), an age-related disorder, is characterized by the gradual accumulation of Aβ proteins, primarily in the walls of small cerebral blood vessels.[
According to the literature, suspicion of iCAA should be raised mostly in younger patients presenting with recurrent lobar ICHs. However, iCAA should be suspected in all patients with lobar ICH who have a history of cranial surgery, especially if heterologous dural substitutes were used. Namely several descriptions of older patients with confirmed iCAA have been published recently.[
The aims of this article are twofold: first, to highlight iCAA as a distinct variant of CAA causing recurrent spontaneous lobar ICH, and second, to raise awareness about the potential risk of prion-like Aβ protein transmission through heterologous dural grafts while emphasizing the value of the simplified Edinburgh criteria as a possible alternative to the MRI-based Boston criteria.[
This article is based on the previously published two-case report from a single institution featuring patients diagnosed with iCAA by vascular neurologists and managed by neurosurgeons.[
MATERIALS AND METHODS
This paper presents two illustrative cases of iCAA[
The presence of CAA was evaluated using the simplified Edinburgh criteria [
The simplified Edinburgh criteria categorize brain CT findings into three probability tiers: high probability of CAA, characterized by lobar ICH accompanied by subarachnoid hemorrhage (SAH) and finger-like projections from the ICH; intermediate probability, defined as lobar ICH associated with isolated SAH; and low probability when lobar ICH occurs without accompanying SAH. A high probability of CAA, identified by the presence of all three CT predictors, demonstrates 100% specificity in confirming the association between CAA and lobar ICH.[
RESULTS
Case one
A 46-year-old female was admitted to the Department of Neurology at UMC Ljubljana with severe headache, vomiting, and left-sided hemiplegia, followed by rapid onset of stupor.[
Figure 1:
(a) A head computed tomography (CT) scan of the patient at the time of admission. A large intracerebral hemorrhage (ICH) in the right fronto-parietal area can be seen, extending down into the basal nuclei. The right hemisphere is compressed and liquor spaces are obliterated, as well as the right lateral ventricle. In the left temporo-frontal area, the deformed cranial bone can be seen after previous surgery in childhood (arrows). (b) Postoperative CT scan of the same patient. An area of decompressive craniectomy with numerous scattered ICHs is evident. Most of the right hemisphere is filled with an area of irregular hematoma with adjacent edematous brain substance. Pronounced extracranial herniation of virtually the entire right cerebral hemisphere and pronounced left-sided subfalcine herniation is discernible (dotted arrow). (c) The control postcontrast CT scan was taken a few weeks after the initial insult. Extensive scattered new abscesses with surrounding edema in the right cerebral hemisphere can be seen. (d) The last CT scan. A relapsing ICH in the right hemisphere is present, as is edema, and pronounced right to left shift of the brain substance.
Based on the simplified Edinburgh CT criteria, and taking into account the substantial baseline volume of the ICH exceeding 40 mL, the probability of CAA was considered highly likely, with a high risk for CAA-associated ICH. Several weeks later, follow-up CT imaging showed relapsing ICH in the right hemisphere with concomitant brain edema [
Case two
A 52-year-old male was first admitted to UMC Ljubljana 7 years ago following a spontaneous ICH in the right frontal lobe.[
Figure 2:
(a) The initial brain computed tomography (CT) showing a large intracerebral hemorrhage (ICH) in the right frontal corticosubcortical area. In the left frontopolar area, an up to 2 cm large area of cortical atrophy and encephalomalacia of the inferior white matter is discernible – a condition after old traumatic brain injury following surgical intervention (arrows). (b) The second bleeding revealed an ICH in the left frontal area. Hypodense area in the right parietal area can be seen – a condition after previous bleeding. (c) The third intracranial bleeding is documented in a CT scan. A large fresh hematoma in the right occipitotemporal area with minimal surrounding edema is present (a-c: arrows).
At the age of 7, the patient sustained a skull fracture and brain contusion following a sledding accident, necessitating neurosurgical intervention through osteoplastic craniotomy. The procedure was completed by alloplastic dural grafting since the dura and the underlying brain substance were also severed. He was not exposed to cadaveric human growth hormone, but he did receive blood transfusions. The patient recovered well after this injury and did not experience any neurological consequences.
Based on the simplified Edinburgh CT criteria, regarding the smaller volume of the ICH, the diagnosis of CAA was considered likely, and according to the diagnostic criteria proposed by Banerjee et al., it was assessed as possible iCAA.[
DISCUSSION
Our paper presents two cases of iCAA in middle-aged patients who underwent neurosurgical procedures in childhood for different conditions. In both cases, cadaveric dura was used during surgery as a dural substitute for brain covering. In the first patent, the initial cause of the surgery was a low-grade glioma, while in the second, the allograft dura was implanted for the treatment of traumatic brain injury. Decades later, both patients developed early-onset CAA. The preliminary diagnosis in both cases was made using the simplified Edinburgh CT criteria, based solely on brain CT imaging, with the definitive diagnosis of CAA in Case 1 confirmed postmortem through autopsy. The Edinburgh criteria seem to have good sensitivity (over 80%) with an ICH volume of ≥40 mL, whereas in ICH volumes <15 mL, the sensitivity is below 50%.[
The proposed diagnostic criteria by Banerjee et al. provided a reliable framework for classifying the condition as either probable or possible, with the first case classified as probable and the second one as possible.[
Our paper highlights two key points: first, cadaveric dural grafts were used in childhood for different pathologies, and second, both patients later developed iCAA, underscoring the potential long-term risks associated with dural transplantation. Importantly, the initial diagnosis in these cases was made using the simplified Edinburgh CT criteria, which, although less commonly cited than the MRI-based Boston criteria, may become a possible diagnostic tool. However, the CT-based Edinburgh criteria reliability is significantly dependent upon the ICH volume. Therefore, they should be applied with caution in small-sized lobar ICHs.[
Prion diseases are transmissible neurodegenerative disorders characterized by the accumulation of abnormal prion proteins in the brain.[
An age-related prion-like disorder, CAA is characterized by the gradual accumulation of Aβ proteins in the walls of small cerebral vessels. Advancing age is the primary risk factor for its development.[
Distinguishing iCAA from sporadic CAA in this paper was grounded on a documented history of the disease. The manuscript’s findings are specific to iCAA because our patients of relatively younger age have undergone cranial surgeries during their childhood and met the simplified Edinburgh criteria (with the second case being “borderline” due to a small baseline ICH volume), which may correlate well with the proposed diagnostic criteria by Banerjee et al. However, it is important to note that the proposed criteria by Banerjee et al. have not been validated.[
Historically, neurosurgeons and suppliers of surgical materials prioritized achieving an adequate seal for dural defects, often overlooking the long-term risks of iatrogenic transmission. Dural grafting was commonly performed using autografts or cadaveric allografts, including human and bovine lyophilized transplants. Years ago, when our two patients underwent surgical treatment, scanning for prion particles was not available in Slovenia, and awareness of this type of transmission was low.
From the neurosurgical point of view, there is uncertainty surrounding the risk of iatrogenic transmission of CJD and the effectiveness of strategies to mitigate the iCAA risk, which remains rare in standard clinical practice. An overview of commercial cadaveric dural substitutes shows a gradual decline in their use in neurosurgical practices over the past 50 years,[
In the early 1990s, while assessing optimal dural closure techniques in patients with war-related brain injuries, we observed the benefits of autologous dural grafts over cadaveric transplants, such as faster healing and reduced cortical scarring, potentially lowering the risk of posttraumatic seizures.[
The ideal dural substitute should effectively restore the integrity of a dural defect while demonstrating biomechanical properties comparable to those of autologous transplants. It should facilitate autologous healing and support structural and functional repair, promoting healthy tissue growth to prevent cerebrospinal fluid leaks and inhibit cortical scarring.[
The limitations of this study include its retrospective design, reliance on previously published cases, and the single-center nature with a small sample size. In addition, in the second case, a biopsy was not performed to obtain a definitive CAA diagnosis. Given this consideration, the conclusions drawn must be interpreted with caution.
To deepen our understanding of the clinical and pathological features of iCAA, further research involving larger, multi-center studies is essential, although this may be problematic due to the avoidance of cadaveric transplants (dural grafts) in neurosurgery, particularly in recent years as awareness of CJD transmission has increased. At present, the use of modern and safer synthetic or organic allogeneic dural substitutes is becoming increasingly common.
CONCLUSION
iCAA, a distinct form of CAA, is characterized by earlier symptom onset in younger patients. This emerging condition should be considered when prion-like disease transmission is suspected following various neurosurgical procedures. The simplified Edinburgh CT criteria can be used to evaluate the diagnosis of CAA, while the proposed diagnostic criteria by Banerjee et al. may offer an accurate, though not validated, method for identifying iCAA.
It is important to raise awareness in patients with a history of exposure to prion-contaminated materials, such as cadaveric or bovine lyophilized dural grafts. Although the risk of transmission has decreased with advanced techniques and polymeric dural substitutes, caution remains essential. Implementing preventive measures is vital to reducing the risk of iCJD and iCAA transmission in neurosurgical patients.
Authors’ contributions
All authors contributed to conceptualization, writing, review, and editing. All authors gave their final approval for this version to be published.
Ethical approval
Institutional Review Board approval is not required.
Declaration of patient consent
Patient’s consent not required as patients identity is not disclosed or compromised.
Financial support and sponsorship
Nil.
Conflicts of interest
There are no conflicts of interest.
Use of artificial intelligence (AI)-assisted technology for manuscript preparation
The authors confirm that there was no use of artificial intelligence (AI)-assisted technology for assisting in the writing or editing of the manuscript and no images were manipulated using AI.
Disclaimer
The views and opinions expressed in this article are those of the authors and do not necessarily reflect the official policy or position of the Journal or its management. The information contained in this article should not be considered to be medical advice; patients should consult their own physicians for advice as to their specific medical needs.
References
1. Azzam D, Romiyo P, Nguyen T, Sheppard JP, Alkhalid Y, Lagman C. Dural repair in cranial surgery is associated with moderate rates of complications with both autologous and nonautologous dural substitutes. World Neurosurg. 2018. 113: 244-8
2. Banerjee G, Samra K, Adams ME, Jaunmuktane Z, Parry-Jones AR, Grieve J. Iatrogenic cerebral amyloid angiopathy: An emerging clinical phenomenon. J Neurol Neurosurg Psychiatry. 2022. p. jnn2022-328792
3. Banerjee G, Adams ME, Jaunmuktane Z, Alistair Lammie G, Turner B, Wani M. Early onset cerebral amyloid angiopathy following childhood exposure to cadaveric dura. Ann Neurol. 2019. 85: 284-90
4. Bonda DJ, Manjila S, Mehndiratta P, Khan F, Miller BR, Onwuzulike K. Human prion diseases: Surgical lessons learned from iatrogenic prion transmission. Neurosurg Focus. 2016. 41: E10
5. Brown P, Brandel JP, Preece M, Sato T. Iatrogenic CreutzfeldtJakob disease: The waning of an era. Neurology. 2006. 67: 389-93
6. Brown P, Brandel JP, Sato T, Nakamura Y, MacKenzie J, Will RG. Iatrogenic Creutzfeldt-Jakob disease, final assessment. Emerg Infect Dis. 2012. 18: 901-7
7. Charidimou A, Boulouis G, Frosch MP, Baron JC, Pasi M, Albucher JF. The Boston criteria version 2.0 for cerebral amyloid angiopathy: A multicentre, retrospective, MRIneuropathology diagnostic accuracy study. Lancet Neurol. 2022. 21: 714-25
8. DiFrancesco JC, Tabaee Damavandi P, Pretnar-Oblak J, Frol S, De La Riva Juez P, Albajar Gomez I. Iatrogenic cerebral amyloid angiopathy after red blood cell transfusion?. Eur J Neurol. 2024. 31: e16366
9. Duffy P, Wolf J, Collins G, DeVoe AG, Streeten B, Cowen D. Letter: Possible person-to-person transmission of CreutzfeldtJakob disease. N Engl J Med. 1974. 290: 692-3
10. Esmonde T, Lueck CJ, Symon L, Duchen LW, Will RG. Creutzfeldt-Jakob disease and lyophilised dura mater grafts: Report of two cases. J Neurol Neurosurg Psychiatry. 1993. 56: 999-1000
11. Fabjan M, Jurečič A, Jerala M, Oblak JP, Frol S. Recurrent intracerebral haematomas due to amyloid angyopathy after lyodura transplantation in childhood. Neurol Int. 2024. 16: 327-33
12. Greenberg SM, Charidimou A. Diagnosis of cerebral amyloid angiopathy: Evolution of the Boston criteria. Stroke. 2018. 49: 491-7
13. Greenberg SM. Cerebral amyloid angiopathy: Prospects for clinical diagnosis and treatment. Neurology. 1998. 51: 690-4
14. Greenberg SM, Charidimou A. Seed to bleed: Iatrogenic cerebral amyloid angiopathy. Stroke. 2023. 54: 1224-6
15. Jaunmuktane Z, Mead S, Ellis M, Wadsworth JD, Nicoll AJ, Kenny J. Evidence for human transmission of amyloid-β pathology and cerebral amyloid angiopathy. Nature. 2015. 525: 247-50
16. Khurana D, Suresh A, Nayak R, Shetty M, Sarda RK, Knowles JC. Biosubstitutes for dural closure: Unveiling research, application, and future prospects of dura mater alternatives. J Tissue Eng. 2024. 15: 20417314241228118
17. Kizmazoglu C, Aydin HE, Kaya I, Atar M, Husemoglu B, Kalemci O. Comparison of biomechanical properties of dura mater substitutes and cranial human dura mater: An in vitro study. J Korean Neurosurg Soc. 2019. 62: 635-42
18. Kothari RU, Brott T, Broderick JP, Barsan WG, Sauerbeck LR, Zuccarello M. The ABCs of measuring intracerebral hemorrhage volumes. Stroke. 1996. 27: 1304-5
19. Manix M, Kalakoti P, Henry M, Thakur J, Menger R, Guthikonda B. Creutzfeldt-Jakob disease: Updated diagnostic criteria, treatment algorithm, and the utility of brain biopsy. Neurosurg Focus. 2015. 39: E2
20. Nafe R, Arendt CT, Hattingen E. Human prion diseases and the prion protein-what is the current state of knowledge?. Transl Neurosci. 2023. 14: 20220315
21. Ornello R, Colangeli E, Tommasino E, Tiseo C, Perrotta G, Scarpato C. Clinical usefulness of Edinburgh CT criteria in patients with lobar intracerebral hemorrhage. Eur Stroke J. 2021. 6: 36-43
22. Panteleienko L, Mallon D, Oliver R, Toosy A, Hoshino Y, Murakami A. Iatrogenic cerebral amyloid angiopathy in older adults. Eur J Neurol. 2024. 31: e16278
23. Peden AH, Head MW, Ritchie DL, Bell JE, Ironside JW. Preclinical vCJD after blood transfusion in a PRNP codon 129 heterozygous patient. Lancet. 2004. 364: 527-9
24. Pikija S, Pretnar-Oblak J, Frol S, Malojcic B, Gattringer T, Rak-Frattner K. Iatrogenic cerebral amyloid angiopathy: A multinational case series and individual patient data analysis of the literature. Int J Stroke. 2024. 19: 314-21
25. Prusiner SB. Prions. Proc Natl Acad Sci U S A. 1998. 95: 13363-83
26. Raposo N, Planton M, Siegfried A, Calviere L, Payoux P, Albucher JF. Amyloid-β transmission through cardiac surgery using cadaveric dura mater patch. J Neurol Neurosurg Psychiatry. 2020. 91: 440-1
27. Rodrigues MA, Samarasekera N, Lerpiniere C, Humphreys C, McCarron MO, White PM. The Edinburgh CT and genetic diagnostic criteria for lobar intracerebral haemorrhage associated with cerebral amyloid angiopathy: Model development and diagnostic test accuracy study. Lancet Neurol. 2018. 17: 232-40
28. Schmalz P, Griessenauer C, Ogilvy CS, Thomas AJ. Use of an absorbable synthetic polymer Dural substitute for repair of Dural defects: A technical note. Cureus. 2018. 10: e2127
29. Van Etten ES, Kaushik K, Van Zwet EW, Voigt S, Van Walderveen MA, Van Buchem MA. Sensitivity of the Edinburgh criteria for lobar intracerebral hemorrhage in hereditary cerebral amyloid angiopathy. Stroke. 2020. 51: 3608-12
30. Vranković D, Hećimović I, Splavski B, Dmitrović B. Management of missile wounds of the cerebral Dura mater: Experience with 69 cases. Neurochirurgia (Stuttg). 1992. 35: 150-5
31. Wroe SJ, Pal S, Siddique D, Hyare H, Macfarlane R, Joiner S. Clinical presentation and pre-mortem diagnosis of variant Creutzfeldt-Jakob disease associated with blood transfusion: A case report. Lancet. 2006. 368: 2061-7
32. Yamada M, Hamaguchi T, Sakai K. Acquired cerebral amyloid angiopathy: An emerging concept. Prog Mol Biol Transl Sci. 2019. 168: 85-95
